Emissivity Black Body Temperature Radiation Source 0.99 with 110-220V AC Power Supply

Name: Emissivity Black Body Temperature Radiation Source 099 with 110220V AC Power Supply
Brand: Dearto
Price: 1 USD

China Emissivity Black Body Temperature Radiation Source 0.99 with 110-220V AC Power Supply wholesale

Warranty : 1 year

Customized support : OEM, ODM, OBM

Place of Origin : Shandong, China

Brand Name : Dearto

Model Number : DTM-3050BSG

Display resolution : 0.01℃

Emissivity : 0.98 ± 0.01

Dimensions(mm) : 250*140*180

Power supply : 110-220V AC, 50Hz

Net Weight : 2kg

Certification : ISO9001

Packaging Details : Carring case

Supply Ability : 400 Set/Sets per Month

Price : $1,500.00 - $2,000.00/pieces

MOQ : 1

Contact Now

Products Description

DTM-3050BSG is a small size blackbody calibration source utilizing a digital indicating temperature ambient 30℃ to 50℃ (86F to 122F). A 70x70mm size ridged plate is heated or cooled with an internal solid state thermoelectric heat pump. It has a built-in digital temperature controller to provide accurate, stable temperature as well as to provides readout.

APPLICATION
1. Ambient temperature compensation for thermal image camera
2. Test infrared thermometer

Main features

l 0.05℃ high stabillity
l Calibrate from 30℃ to 50℃
l Quickly heat up to 50℃ in 10 minutes
l Target size is 70mm x 70mm
l Built-in temperature correction function
l Quick and easy operate
l Portable and light weight

Product Paramenters

Temperature range	30 ºC~50 ºC (The set temperature must be at least 2 ºC higher than the ambient temperature.)
Black body cavity area	70 x 70 mm
Black body cavity emissivity	ε= 0.98±0.01
Temperature controller	EPC3016, standby RS232 port
Radiation temperature uncertainty	≤0.1ºC
Temperature stability	≤0.05ºC/30 min
Temperature control ambient temperature coefficient	±0.01 ºC /10 ºC(Typical value)
Ambient temperature	10 ºC ~32ºC, no condensation
Power supply	110/220V ± 10%，100W
